Single Channel Wireless Control OEM Kit 12VDC
Kit supplied with:  1 Transmitter, 1 Receiver, 2 Antennas,  Instructions

Transmitter and Receiver Antenna     Range



Wiring Example*







■ 1200 ft   ( 400 meter ) line-of-sight

■ Input Dry isolated contact N/O
■ Relay output SPDT 6 Amp 240V/30V
■ Power input 12VDC 500mA ea

6" Omni Antenna  938091 Short Range  (Two)
433 MHz, Unity gain, 50 ohms  Magnetic base
With 60 inch Coax Cable and SMA m connector

SPECIFICATIONS     Picture

9312811   $599.99






    Wiring Example*





■   2000 ft   ( 600 meter ) line-of-sight

■ Input Dry isolated contact N/O
■ Relay output SPDT 6 Amp 240V/30V
■ Power input 12VDC 500mA ea

14" Omni Antenna 938092   (Two)
 433 MHz, 3dBi  gain, 50 ohms Magnetic base
With 120 inch (3M) Coax Cable and SMA m connector
SPECIFICATIONS

9312812    $629.99





    Wiring Example*


■
2 Mile  ( 3 Km ) line-of-sight

■ Input Dry isolated contact N/O
■ Relay output SPDT 6 Amp 240V/30V
■ Power input 12VDC 500mA ea

3 Element Beam  Yagi Antenna 938432   (Two)
433 MHz, Gain: 7 dBi  Rating: 150 Watts
with 10 ft coax cable and connector 938666

SPECIFICATIONS

9312814  $799.99





    Wiring Example*


4 Mile  ( 6 Km ) line-of-sight

■ Input Dry isolated contact N/O
■ Relay output SPDT 6 Amp 240V/30V
■ Power input 12VDC 500mA ea

5 Element Beam  Yagi Antenna 938455   (Two)
433 MHz, Gain: 9 dBi  Rating: 150 Watts
with 10 ft coax cable and connector 938666

SPECIFICATIONS

9312815  $999.99





Wireless Control System with
OPTIONAL DIN Power Supply

■  DIN Power Supply
  • Regulated Output Voltage: 12 VDC
  • Power  15W
  • Current  1.2A , 1200mA
  • Power input  range 85-240VAC
  • DIN, rugged plastic housing
  • Operating Temperature: -10 to 70 Celsius
  • UL Listed CSA Certified
  • Low profile, Dimension: W,H,D
    1.0 x 3.5 x 2.2 inches,  25 x 89 x 56 mm

931215    $39.99 each



  Wiring Example*




Special configuration  Request form

RF Coaxial Cable Set

10 Feet RG58 Coax with N Male & SMA Male

938666    $49.99


30 Feet Low Loss RG8 Coax with N Male & SMA Male

938667    $149.99




DISCLAIMER:  Radio control equipment in not to be used in life safety. Radio Installations shall be performed by a certified professional.
